New-Gen Mercury 7 II

LTA approved Level-2 Portable EV Charger by Quickcharge

Portable EV charger that is compact and compatible with all EV models

New Gen Mercury 7 II by Quickcharge

Quickcharge Mercury 7 II is one of the few Level 2 portable EV charger that is compliant with Singapore EV charging regulatory standards, that is compatible with all EV models, indoors and outdoors! Fitting into a compact 20cm x 9cm portable bag, place it in the car boot and drive with a peace of mind wherever you are.
About Mercury 7 II Portable EV Charger

Experience the power of affordable, efficient charging with the Mercury 7 II portable charger. This charger provides unparalleled convenience and safety, all at a budget-friendly price.

Affordable, Convenient, Safe.

Have quick charging at your fingertips! Featuring an easy-to-use interface that displays the current level and charging schedule, Mercury & II ensures a safe and seamless charging experience.

New Gen Mercury 7 II

Level 2 EV Charging Speed

Up to 7.4Kw that can charge up to 40km in an hour. (*Distance varies based on EV models)

LTA Approved

Compliance with Singapore EV charging regulatory standards (TR25:2016, LNO. CE)

5 metres

Long cable length to ensure ease of connection from power source to car.

Lightweight Convenience

Comes with a portable box measuring 20cm x 9cm x 4cm to easily fit in any car boot.

Easy Configurations

Ability to switch charging current and time easily.

Rainproof / Dustproof

Outdoor IP 67 Grade (function box) with overvoltage and undervoltage protection

Level 2 EV Charging Speed

Up to 7Kw that can charge up to 40km in an hour. (*Distance varies based on EV models)

LTA Approved

Compliance with Singapore EV charging regulatory standards (TR25:2016, LNO. CE)

5 metres

Long cable length to ensure ease of connection from power source to car.

Lightweight Convenience

Comes with a portable box measuring 20cm x 9cm x 4cm to fit in car boot.

Easy Configurations

Ability to switch charging current and time easily.

Rainproof / Dustproof

Outdoor IP 67 Grade (function box) with overvoltage and undervoltage protection

Key features

Level 2 Fast Charge

12-Point Safety Protections

Lightweight

Compatible with all EVs

IEC 62752-2018

IEC 62196-1

IEC 61851-1

Product Information
Charging ModeMode 2
Input/ Output Power & Current Rating7.4kW / 32A max.
Input/ Output Voltage/ FrequencyAC 230V/50Hz
Charging Current Setting10/16/25/32A
Charging Schedule1/2/3/4/5/6/7/8H
Standby Power Consumption≤5W
Insulation Resistance>10MΩ
Residual Current ProtectionType A + DC 6mA
Overvoltage Protection≥275V±5V continued 5s
Undervoltage Protection≤75V±5V continued 5s
Charging Cable LengthAppr. 5m
Dimension200x90x40mm (LxWxH)
IP Grade Outdoor IP 67 (function box)
Ambient Temperature -30°C ~ +50°C
Storage Temperature -40°C ~ +85°C
Ambient Humidity ≤95% RH no condensation
Standards and Compliance IEC 62752-2018, IEC 62196-1, IEC 61851-1
Certification TR25:2016, LNO, CE

New-Gen Mercury 7 II FAQs

Get answers to commonly asked questions about New-Gen Mercury 7 II by Quickcharge.

This is a portable charger that can be brought to any place. It is known as a mode 2 charger, while public chargers are typically mode 3 and mode 4 chargers.

It is compatible with all vehicles that have a CCS2 connector, which is the most common type of connector on the EV vehicles in Singapore.

The power rating is 7kW. This charger allows the user to adjust the current rating, ranging from 10A to 32A, which translates to a range of 2.4kW to 7kW.

It depends on your vehicle’s battery capacity and the power output. If your vehicle’s battery capacity is 50kWh and you set the power to 7kW, it will take approximately 7.14 hours to fully charge the vehicle.

It is the most affordable solution in the market for a TR25 and LNO approved Mode 2 charger.

You will need a 3-pin 32A CEE form female socket. Depending on cable length, a typical installation cost for this type of plug for a landed property ranges from $1.3k to $1.5k before gst.

No. According to TR25, you need to have a mechanical interlocked switch socket-outlet conforming to the IEC 60309 standard for a mode 2 charger.

For the CEE form socket, we recommend having a certified LEW for installation. Our charger does not require LEW sign-off.

Yes, you will need to register with the LTA via the OneMotoring website. No future inspections are required.

Plug it into the power source, turn on the power supply, adjust the current and desired time, and then plug it into your vehicle. The charging will start automatically.

Vehicle pulsating
DC leakage protection
Pressure resistant
Flame retardant
Electrostatic
protection
Earthing detection
Protection
Crush
Test
Circuit Board
Temperature Sensor
Under Voltage
Protection
Lightning
Protection
Over Voltage
Protection
Waterproof
Protection
Intelligent
Kernel
Over Current
Protection
Vehicle pulsating
DC leakage protection
Pressure resistant
Flame retardant
Electrostatic
protection
Earthing detection
Protection
Crush
Test
Circuit Board
Temperature Sensor
Under Voltage
Protection
Lightning
Protection
Over Voltage
Protection
Waterproof
Protection
Intelligent
Kernel
Over Current
Protection
30-Day Money-Back Guarantee

Return the product to us anytime within 30-days of purchase and receive a full refund. No questions asked.

1 Year Warranty

Complimentary 1-year warranty. Simply register online on the day of delivery / collection.

Installation Service

Arrange a date with our engineers to install Mercury 7 II as a fixed charging station at your premises.
