New-Gen Mercury 7 II
Level 2 Portable EV Charger.
Purchase Mercury 7 II today.
"*" indicates required fields
Product Information
Charging Mode | Mode 2 |
Input/ Output Power & Current Rating | 7.4kW/ 32A max. |
Input/ Output Voltage/ Frequency | AC 230V/50Hz |
Charging Current Setting | 10/16/25/32A |
Charging Schedule | 1/2/3/4/5/6/7/8H |
Standby Power Consumption | ≤5W |
Insulation Resistance | >10MΩ |
Residual Current Protection | Type A + DC 6mA |
Overvoltage Protection | ≥275V±5V continued 5s |
Undervoltage Protection | ≤75V±5V continued 5s |
Charging Cable Length | Appr. 5m |
Dimension | 200x90x40mm (LxWxH) |
IP Grade | Outdoor IP 67 (function box) | |
Ambient Temperature | -30°C ~ +50°C | |
Storage Temperature | -40°C ~ +85°C | |
Ambient Humidity | ≤95% RH no condensation |
Standards and Compliance | IEC 62752-2018, IEC 62196-1, IEC 61851-1 | |
Certification | TR25:2016, LNO, CE |
