Artemis 22

Design

Excellent industrial design brings pleasant user experience

Resistant

The shell material is polycarbonate, IP55, enabling waterproof, dustproof, and flame-retardant capabilities.

Universal Backend

Connect to any backend based on OCPP 1.6J protocol

Connectivity

4G, Wi-Fi, Ethernet, Bluetooth (configurable options)

Design

Excellent industrial design brings pleasant user experience

Resistant

The shell material is polycarbonate, IP55, enabling waterproof, dustproof, and flame-retardant capabilities.

Universal Backend

Connect to any backend based on OCPP 1.6J protocol

Connectivity

4G, Wi-Fi, Ethernet, Bluetooth (configurable options)

Model Name Artemis 22
Input Rating 340-460Vac±10%, Three phases, 50/60Hz±5%, L1+L2+L3+N+PE (support single phase input)
Output Power 22kW
Output Current 32A max
Status Indicators LED indicator
Buttons and Switch Emergency switch (optional), with rotary switch inside (used for setting output current limitation)
Card Reader ISO/IEC 14443 A/B, ISO/IEC 18092, IEC/ISO 15693
Network Interface 4G, Wi-Fi, Bluetooth(optional), Ethernet, RS485
Protocol (EVSE&Backend) OCPP 1.6J
Protocol (EVSE&EV) Control pilot, ISO 15118 (Hardware ready)
Dimension (W x H x D) 280 x 280 x 148 mm
(Pole: 100 x 1210 x 50 mm)
Weight Approx. 6.1kg
Installation Wall mounting, Pole mounting (Pole is optional)
Certificate / Compliance IEC 61851-1, IEC 62955, IEC 61851-21-2, LVD 2014/35/EU, RED 2014/53/EU, IEC 62955 (RCD), 2014/32/EU (Metering), RoSH 2.0, REACH
